MOUNTING SYSTEM
SUMS - Designed & Certified by Eclipse Technics
A revolutionary new way to install the JetWave™ Ka-Band FMA Satcom System
Current generation Ka and Ku band satcom systems are allowing for far greater connectivity in the air. However, this technology comes with the complexity that accompany very large antennas.
Modifying your aircraft to add a large antenna can ultimately result in significant fuel burn increases, reduced airframe life, increased costly and repetitive maintenance tasks, limitation of re-sale and/or leasing options, and impact on long-term service options.
Until now.
Light, non-intrusive
Total weight (kg/lbs) : 69-78 / 154-174
Dimensions (m) : 2.6 x 1.1 x 0.4
Safe
Aircraft reinforcements & associated fittings including skirt fairing assy.
Modular
Two attachment options : ARINC791 or Top of frames, KRFU inside or outside
Easy to install/maintain
150 man hours to install. Easy access to LRUs.
Cost savings
No structural doubler required : fewer part numbers, more efficient.
Multiple STCs
STCs for Airbus & Boeing. Ready to use on single-aisle & wide-body aircraft.
